| ブランド名: | ZXY |
| MOQ: | 交渉可能 |
| 価格: | 交渉可能 |
| パッケージの詳細: | カートン |
| Feature Category | Performance Characteristic | Typical Value / Description |
|---|---|---|
| Electrical Performance | High Operating Frequency | 20 kHz to 500 kHz operation for high power density and reduced component size |
| Electrical Performance | Conversion Efficiency | ETD core shape reduces copper and core losses, achieving >85%-90% efficiency |
| Electrical Performance | Power Handling Range | 15W to 150W+ depending on circuit topology (Flyback, Forward, LLC) |
| Safety & Isolation | High Withstand Voltage | 3000VAC to 4000VAC primary to secondary isolation rating |
| Safety & Isolation | Insulation Grade | Meets UL, CE standards with reinforced insulation layers |
| Magnetic & Thermal | Low Core Loss | Ferrite materials (PC40, PC44) minimize hysteresis and eddy current losses |
| Magnetic & Thermal | Low Leakage Inductance | Bobbin structure and winding techniques control leakage inductance |
| Magnetic & Thermal | Operating Temperature Range | -40°C to +125°C stable operation in harsh environments |
| Mechanical | Vertical Mounting | Saves PCB space and facilitates better heat dissipation |
| Mechanical | Magnetic Shielding | Closed-core ETD design reduces Electro-Magnetic Interference (EMI) |
|
|
